WZ series weightless mixer

Working principle

This series of mixers is characterized by strong and efficient mixing, with two stirrers in the horizontal cylinder rotating in opposite directions at equal speeds. The specially arranged blades ensure the radial, circumferential, and axial movement of the material, forming a composite cycle and achieving uniform mixing in an extremely short time.

Product Features

1. High mixing accuracy, fast speed, low energy consumption, and sealable operation.

2. Pneumatic, electric, and manual discharge methods.

3. Atomization devices can be arranged on the cylinder cover to achieve solid-liquid mixing.

Application scope

Drying and mixing of chemicals, detergents, coatings, resins, glass silicon, pigments, pesticides, fertilizers, feed, feed additives, wheat flour, milk powder, spices, trace ingredients, coffee, salt, additives, plastics, and various sizes and powders.

Technical specifications

Model specifications	WZ-0.05	WZ-0.1	WZ-0.3	WZ-0.5	WZ-1	WZ-2	WZ-3	WZ-4	WZ-6
Mix once kg	24-30	40-60	120-180	200-300	400-600	800-1200	1200-1800	1600-2400	2400-3600
Installed power kw	2.2	3	4-5.5	5.5-7.5	7.5-11	11-15	18.5-22	22-30	30-37
Equipment weight kg	250	360	750	880	2100	2740	3800	5100	6200
